Atom-thin quantum materials step out of the lab, but the manufacturing gap is the story

A photonics lab at the City College of New York has spent the past several years reducing quantum materials to their thinnest possible expression, single atomic layers stacked and twisted into structures that behave in ways bulk crystals never did. On 14 July 2026, that programme published a formal claim to the frontier: a perspective article that names atomically thin quantum systems as the field's next organising problem, and that lays out the experimental building blocks the community will need to master before the technology leaves the lab bench.

The framing matters because quantum materials have spent a decade moving from physics curiosity to industrial priority. Governments from Washington to Seoul to Beijing have placed versions of the technology at the centre of their industrial-policy stacks, with quantum computing, quantum sensing and quantum communications all flagged as strategic. Defining what counts as a quantum material, and where the production bottlenecks actually sit, is the kind of work that quietly shapes which countries end up controlling which supply chains. The CCNY perspective is the kind of paper that reads as pure science and acts as industrial policy.

The promise of single-layer systems

Vinod M. Menon's group, the Laboratory for Nano and Micro Photonics (LaNMP) at City College, has built its recent reputation on a simple trick: take a material that only behaves interestingly in bulk, peel it down to a single atomic layer, and watch how its optical and electronic rules change. The family of materials in question covers transition-metal dichalcogenides, black phosphorus and a growing list of so-called van der Waals crystals, layered solids whose atoms bond tightly within each sheet but only weakly to the sheet above and below. That weak interlayer coupling is what makes exfoliation, and the controlled restacking of different sheets into so-called heterostructures, possible at all.

The Physics-published perspective (T"orma et al., 2026) that LaNMP contributed to argues that these single-layer systems and their stacked cousins represent the next platform for quantum phenomena that previously demanded cryogenically cooled bulk crystals. The argument runs that confinement to two dimensions amplifies electron-electron interactions, that stacking different monolayers creates artificial lattices with no natural equivalent, and that the resulting structures can host strong light-matter coupling at room temperature, the operational regime photonics and sensing applications actually need.

The practical implication is a list of device architectures: room-temperature single-photon emitters for secure communications, ultra-thin photodetectors for imaging beyond the visible band, and exotic platforms such as moiré exciton condensates that could become the basis of new types of optical switches. None of those are mature products. All of them sit closer to realisation than they did five years ago, which is exactly the gap industrial policy is trying to close.

Where the bottleneck actually sits

The physics is moving faster than the manufacturing. Producing a single, near-perfect monolayer of a transition-metal dichalcogenide is still an exercise in artisanal chemistry. Chemical vapour deposition, the dominant synthesis route, produces flakes whose quality varies from run to run and from reactor to reactor. Picking up one of those flakes, identifying it under a microscope, and stacking it precisely on top of another flake, often at a controlled twist angle, is a process that today requires a cleanroom, a micromanipulator and a graduate student with a steady hand.

That is the gap the CCNY-led perspective is naming. The paper frames the next decade of work as much around manufacturing science, metrology and wafer-scale integration as around new physics. That framing has been echoed in industrial-policy documents from Washington and Brussels, which have both flagged quantum materials and their fabrication equipment as priority supply-chain investments. The implicit argument is that whoever solves the production problem first sets the price, the standards and the export controls for everyone else.

A genuinely global race

The work at CCNY sits inside a much wider competitive field. South Korea has committed roughly three trillion won to a national quantum strategy that explicitly covers materials. China's central government has folded quantum technology into its broader push for scientific self-reliance, and Chinese groups have published prolifically on atomically thin systems since 2023. The European Union's Quantum Flagship has funded materials work as a horizontal layer beneath its computing and communications pillars. In the United States, the National Quantum Initiative has channelled significant funding through the Department of Energy and the National Science Foundation, and the 2025 reauthorisation expanded its materials scope.

What makes atomically thin quantum systems distinctive is that the production tooling is closer to that of advanced semiconductors than to that of bulk-crystal growth. That puts the manufacturing question inside a geopolitically loaded conversation about lithography, deposition and metrology equipment, the same tools that the United States, the Netherlands, Japan and South Korea have spent three years trying to keep out of Chinese hands through export controls. If quantum materials follow the same trajectory as leading-edge chips, the country that masters wafer-scale monolayer synthesis at acceptable yield could end up in a structurally similar position.

What to watch next

The CCNY paper is a perspective, not a product. Its function is to set a research agenda, and the agenda it sets is unusually explicit about the gap between physics demonstrations and industrial production. Three indicators will tell readers whether the gap is closing.

First, wafer-scale monolayer synthesis. The current state of the art is millimetre-scale flakes. Demonstration of continuous, uniform monolayer films across a two-inch wafer, with reproducible optical properties, would mark a real manufacturing milestone.

Second, integration with conventional photonic platforms. Quantum materials will only matter industrially if they can be coupled to silicon nitride or lithium niobate photonic chips, the workhorses of the broader photonics industry. Published demonstrations of hybrid integration are the second tell.

Third, the export-control calendar. As production capability matures, expect specific deposition and characterisation tools to appear on the restricted lists maintained by Washington and its allies. The first sign that the field has crossed from lab curiosity to strategic industry will be a revision to those lists.

What remains genuinely uncertain is whether any country can hold a structural lead in this corner of quantum technology, or whether the field will fragment the way lithium-ion battery manufacturing did, with no single national champion. The CCNY-led argument is that the production science is still open enough that early-mover advantage is meaningful. The history of other advanced materials suggests it may not be that simple.

Monexus is treating atomically thin quantum materials as an industrial-policy story, not only a physics story. The wire coverage focused on the science; the manufacturing bottleneck and the geopolitical layer around it are where the durable stakes sit.
